Module：300V Max. | PACK：2000V Max.;0~1000A
Designed for battery modules/PACKs for electric vehicles, buses and various energy storage systems, it integrates automated testing, data analysis and efficiency optimization functions, providing one-stop static testing solutions covering off-line inspection and quality control.
RP-EOL-CEP01~04 / RP-EOL-CEM02~04 / RP-EOL-CEPro / RP-EOL-ULP01~04 / RP-EOL-ULM02~04 / RP-EOL-ULPro
Comprehensive testing capabilities that cover all aspects of battery performance evaluation, from basic charge/discharge cycles to advanced high-speed pulse testing.
Advanced engineering design and intelligent software integration that deliver superior performance, reliability, and ease of operation for all battery testing requirements.
Integrated with imported high-precision standard instruments, ensuring reliable and standardized test results;
Supports production verification and R&D research testing modes;
Fully intelligent and automated workflow to reduce operators and improve testing efficiency;
Software supports parsing various BMS communication protocols, transparent parsing without any algorithm processing.
The equipment boasts strong compatibility, meeting diverse testing needs for modules, single enclosures, and PACK packages.
It offers high scalability, allowing for the addition or removal of different functional modules to meet varying battery testing requirements.
It features a self-developed open software platform that supports integrated use with instruments from different brands, maximizing customer satisfaction.
Customized testing functions and projects are available.
Insulation resistance test, DC/AC withstand voltage test, equipotential test
Total voltage, total internal resistance, individual cell voltage drop, NTC accuracy, BMS power consumption
CAN/CANFD, RS485 communication, DBC parsing, UDS diagnostics, CAN terminating resistor
PWM signal, collision signal, charging gun signal, high voltage interlock simulation, insulation leakage simulation
Detailed technical specifications that demonstrate the precision, accuracy, and versatility of our battery testing system for various applications.
Note: For specific models and parameters, please refer to the corresponding technical specifications.
Access technical documentation, brochures, and specifications for our Power Cell Test System.
This system is mainly used for testing, production, and quality control of lithium or lead-acid battery packs in various applications, including electric bicycles, power tools, electric motorcycles, d...
This system is mainly used for new energy vehicles, energy storage, modules, PACK battery systems, and other lithium or lead-acid battery group testing and quality control. Enables integrated charge-d...
Designed for performance testing and quality control of power battery packs and energy storage modules during production, covering finishedand semi-finished products used in electric tools, e-bikes, e...
